Experiment: Control of Citrus Gall Wasp 15


Recently, I posted some observations and theories that I have been developing on citrus gall wasps. To test out the theories, we’re setting up a trial to see which treatment regime might produce the healthiest and most productive trees.

Setting up the Gall Wasp experiment

We used 10 x Meyer Lemon trees in the experiment. They seem very prone to Citrus Gall Wasp.

In August 2017 we purchased 10 Meyer lemon trees. At the time of purchase, they were relatively identical in size, shape and stage of growth. The trees were randomly paired up and allocated to five different treatments:

  • Treatment 1: Citrus Galls pruned out in June every year, fertilized monthly Sep to May.
  • Treatment 2: Citrus Galls pruned out in June every year, fertilized monthly in Dec and Jan only.
  • Treatment 3: Citrus Galls not pruned out, fertilized monthly Sep to May.
  • Treatment 4: Citrus Galls not pruned out, fertilized monthly in Dec and Jan only
  • Treatment 5: Citrus Galls not pruned out, fertilized monthly Sep to May and treated with calcined kaolin clay (Surround®).

The trees were potted up into 40 cm pots and filled with Fulton’s Bulk potting mix. We chose Fulton’s Bulk potting mix as it was an average performer in our recent potting mix trials. This meant that we could control the amount of nitrogen rich fertilizer, that we applied during the first few seasons of growth. A better performing potting mix would have promoted a flush of spring growth regardless of any extra fertilizer that we applied.

We potted up 10 lemon trees. Two trees are each going to be subjected to different treatments.

The plants were placed together to ensure that all experienced similar growing conditions, sunlight, microclimate and irrigation.

There are several large citrus trees growing less than 50 metres from where the experiment is set up. There are other citrus trees visible in nearby neighboring yards. They are all likely to have some Citrus Gall Wasp in them.

Citrus Tree Pruning Regime

Treatments subjected to the “Prune in June” regime (four trees in total) are to have all visible galls pruned from the tree in June. The galls are to be soaked in a bucket of water. None of the purchased trees had any galls present when purchased. We decided to mimic trees that have been infected to speed up the accumulation of results. So approximately one third of the foliage was removed from the trees subjected to the June pruning regimes (despite there being no galls present in the first year). The other six trees will not be pruned at all in June, in any year.

Our citrus trees following our simulated “prune in June” regime in the first year.

All ten trees will be tip pruned as required in/or around November and again in/or around February (if required). Whilst the trees are small, this will be done with secateurs or finger tips. As the trees grow, we may resort to using hedge trimmers. Pruning will aim to retain as much fruit and blossom on the tree as possible. This pruning is a typical regime that I use on most citrus trees (see our guide on citrus tree maintenance for further details)

Fertilizing Regime

Trees are to be fertilized according to one of the following two regimes

  • monthly Sep to May
  • monthly in Dec and Jan only

Trees are fertilized with Richgro Organic Fruit and Citrus Fertilizer, which was the best performing organically certified fertilizer in our recent experiment.

It will be applied at the rate of one handful per pot, per month. The fertilizer will be scattered around the surface and then watered in well.

Calcined Kaolin Clay (Surround®) Regime

The NSW DPI has been trialling some different treatments in commercial citrus orchards. One organic treatment method is showing promise. It involves spraying calcined kaolin clay (Surround®) twice during the citrus gall wasp emergence period. This disrupts the laying of  eggs  and has shown to reduce gall occurrence significantly. We’ve decided to include this treatment as it’s relatively inexpensive, easy to apply and it’s organic.

Calcined Kaolin Clay (Surround®) is to be applied fortnightly for a total of three applications. The first application is to occur in spring at the start of each October. UPDATE 05/12/17: Going forward we will adjust the application of spraying the kaolin clay treatment so that we spray fortnightly applications four times, with the first application in the third week of October (see December 2017 update below)

It is to be applied at the “sunburn rate”. To do this we mixed 8 spoonfuls of power in a small jar of water. This was then tipped into a sprayer and made up to a final volume of 2 litres by adding more water. The trees are to be moved away from the other trees for treatment. The clay is applied using the sprayer and allowed to dry before being returned to their usual position.

Results of Our Citrus Gall Wasp Control Experiment

Update December 2017

The peak emergence for Citrus Gall Wasp in Melbourne looked to occur on (or around) the 28nd November 2017. We filmed the above video of wasps emerging from galls on our tree and mating. I monitored the developing galls and when emergence was imminent we moved all ten trees around the perimeter of our infested grapefruit tree.

Citrus Gall Wasp Melbourne

Our citrus gall wasp experimental trees were temporarily placed around the perimeter of our infested grapefruit tree.

The emergence date was about a fortnight later than we had expected. We had based our expected emergence date on NSW data. Future years’ emergence dates for Melbourne are also likely to be around the same time (late October-early December)  Going forward we will adjust the application of spraying the kaolin clay treatment so that we spray fortnightly applications four times, with the first application in the third week of October.

Citrus Gall Wssp Experiment Melbourne

Flushes of new growth evident on Koalin Treated Tree 5A. This tree is likely to show evidence of gall was infestation next autumn. We will adjust our application of the Kaolin treatment for future yers to better coincide with the gall wasp peak emergence.

The kaolin treatment from this year is likely to be ineffective against the gall wasp. Particularly with tree 5A, as it had a flush of new growth since the final Kaolin application. That new growth had no kaolin on it, leaving it susceptible to infection. I expect this tree to have at least a few galls evident next year.

The following trees had lots of new growth at the time of peak emergence. I expect that they will have a large amount of infestation next year:

1B, 2B, 4B, 5A

The following trees were absent of much new growth at the time of peak emergence. I expect that they will have very little infestation next year.

1A, 2A, 3A, 3B, 4A, 5B

At this stage there is no correlation between the amount of new growth and either fertilizing or pruning regimes. I expect this is because the experiment has only been set up in the last three months. Next spring, once the trees have settled into their growing cycles, a correlation will hopefully be more evident.

All trees have some small fruit set. Tree 2A has the biggest and strongest crop.

Citrus Gall Wasp Experiment Melbourne

All ten Meyer Lemon trees have some fruit set. The fruit on Tree 2A has the largest fruit.

Update June 2018

June is the traditional time to prune out gall wasp. So trees being subjected to Treatment One and Two had their galls pruned out in the last week of June.

At the same time as undertaking pruning we noted lots of observations for each tree. These have been tabulated below.

The following points from this round of observations are most interesting:

  • Trees that have been feed monthly from Sep to May had an average of 2.5 mature lemons per tree vs only 1 mature lemon on average for the trees fed Dec and Jan only. So reducing fertilizing seems to impact productivity significantly.
  • Two treatments did not have any gall wasps present. They were treatment 4 (the reduced fertilizer and no gall removal) and treatment 5 (kaolin treatment)
  • Feeding regimes did not seem to have an impact on susceptibility to Pink scale or induction of flowering.
  • Feeding regimes did not seem to have an impact on susceptibility to Citrus Leaf Miner. In fact, the most severely affected tree was on the reduced fertilizing regime.
  • The kaolin treated trees showed no impact of Citrus Leaf Miner whatsoever. I hope that some residual clay from the previous October/November has interrupted the life cycle of the moth (rather than it just being a coincidence). I am particularly keen to see what happens next autumn with the two trees undergoing the Kaolin treatment regime.
Citrus Gall Wasp Experiment Melbourne

Our ten meyer lemon trees prior to gall wasp removal and fruit harvest

Citrus experiment post removal of galls (for trees undergoing treatment one and two only) and post removal of all mature fruit.

Citrus Fertilizing Melbourne Yellow Leaves

Some of the lemon trees had yellowing leaves

Citrus Leaf Miner Prevention Melbourne

Feeding regimes did not seem to have an impact on susceptibility to Citrus Leaf Miner. However, the trees treated with Kaolin clay had no citrus leaf miner whatsoever.

Citrus Gall Wasp prevention Melbourne

Our Meyer Lemon trees, post gall wasp removal.

Pink Scale Citrus Leaf

This type of Pink Scale was present on many of the trees. Severity of infestation didn’t appear to be linked to any of the fertilizing regimes.

Tree NumberNumber of Citrus Galls present in treeLeaf Miner evident in TreeNumber of mature, ripe lemons on treeNumber of immature, second crop lemons on treeLeaf ConditionOther comments
1A2 x smallModerate40Dark leaves, new growth is lighter in colourFlowers starting to form. Pink scale evident
1B1 x smallVery little11Slight yellowing. New growth has been slightly burnt by frostFlowers starting to form. Pink scale evident
2A4 x small
1 x large
Severe40Light green coloured leavesPink Scale Evident
2B4 smallModerate03Slight yellowing but generally dark green leaves. Pink Scale Evident. Ladybug present.
3A5 smallVery little50Dark green leaves. Lots of new growthLady bugs present, NO scale.
3B3 smallVery little10Several leaves are yellow, otherwise mostly dark greenLots of flowers, NO scale
4AnoneModerate00Slight yellowing of leaves, mostly light greenPink Scale Evident
4BnoneVery little00Moderate amounts of yellowing in leavesLady Bug present, Pink scale evident
5AnoneNone30Slight yellowing of leaves, mostly dark greenPink Scale, Brown scale and Ant present
5BnoneNone20Slight yellowing of leaves, mostly dark greenFlowers starting to form

It is going to be interesting to continue observing the results of the trial. So far, the most promising results have been with the Kaolin treatment. However, we are only a year into the trial, so who knows what the coming years will bring?



Stay Tuned!

This experiment will run for several years. We will be regularly observing  overall tree health as well as  productivity. Periodic updates will be added to this page as the results develop. We will also share them on our Facebook Page and in our newsletter. Sign up to the newsletter so that you don’t miss out on seeing the results.


Leave a comment

Your email address will not be published. Required fields are marked *

15 thoughts on “Experiment: Control of Citrus Gall Wasp

  • Martin T.

    My lemon tree is in the east of Melbourne and the gall wasp population is growing year by year. I do not believe June is the correct month to prune. Take this year I had to prune now to prevent them escaping the tree bark. While pruning a flying gall wasp landed on a branch which I squash with my finger. I don’t believe it came from my tree as they were not hatching out, but from some one else’s tree. With the dry weather maybe the wasps have multiple cycles in a year now ?

    • Leaf, Root & Fruit Post author

      Hi Martin,

      It is interesting that you say you’ve noticed gall wasps emerging now. I’ll keep an eye out on other trees to see if I can also spot some. Perhaps your flying gall wasp was another closely related species rather than the citrus gall wasp?

      Thanks for sharing your experience

      Duncan

  • Murray

    thank you for your time in this matter i will be intrested to now if you have tried taping the affected branch as so the little bastards cannot escape?

    • Leaf, Root & Fruit Post author

      Hi Murray,

      Thanks for your suggestion. No we haven’t tried this. Our efforts have been focused on preventing infection in the first place. If you trap the wasps inside the branch, then the tree is still susceptible to attack from wasps emerging from other trees. It’s also going to be very labor intensive. If you do trial this method, please let us all know how you get on.

      Good Luck and Happy Gardening!

      Duncan

    • Leaf, Root & Fruit Post author

      Hi Jasmine,

      We got ours from a large, rural horticulture supplies. We had to buy it in bulk. We’ll be offering small bags of kaolin clay for sale at the upcoming Spring Into Gardening Festival, where we will have a stall.

      Hope to see you there!

      Duncan

  • Marlene Stagoll

    Your experiment is going to be fabulous and intriguing to follow.

    I decided a couple of years ago to reduce heavy Spring feeding as many pests love that sappy Spring growth
    – aphids, citrus leaf miner, citrus gall wasps, scale.

    I have just liquid fed our citrus which are in the ground with Powerfeed flower And Fruit.
    We will sprinkle a light amount of Sheep manure around the outside of the drip line of these trees.
    Sheepmanure is low in Nitrogen. Sometimes they get worm wee.

    I’ve decided a little feed more often is better for all of our garden plants and maybe we are
    Encouraging pests & viruses with heavy feeds.( & overwatering). Maybe we have all become too enthusiastic
    (& gready!) with lots of Fertilizer.

    I’d like to get hold of some of that Kaolin clay.
    Is it available to purchase in Melbourne?

    Best wishes for your experiment. I look forward to following the results.
    Cheers Marlene

    • Leaf, Root & Fruit Post author

      Hi Marlene,

      Thanks for sharing your insights and experiences. I agree, heavy feeding your trees is akin to feeding them junk food.

      We got our Kaolin clay from a large, rural horticulture supplies. We had to buy it in bulk. We’ll be offering small bags of kaolin clay for sale at the upcoming Spring Into Gardening Festival, where we will have a stall.

      Good Luck & Happy Gardening!

      Duncan

    • Leaf, Root & Fruit Post author

      Hi Jasmine,

      We got ours from a large, rural horticulture supplies. We had to buy it in bulk. We’ll be offering small bags of kaolin clay for sale at the upcoming Spring Into Gardening Festival, where we will have a stall.

      Hope to see you there!

      Duncan

  • Serge

    I have tried Calcined Kaolin Clay (Surround®) on my 10 years old Eureka lemon on 23.10.18
    I’ve noticed that my new growth leaves were badly affected/burned.
    I think it only happened to actively growing leaves – they curled up and and will most likely die.
    I used the recommended rate of application – around 30 ml per liter of water in a 5 liter sprayer tank.
    Any idea what could go wrong?

    • Leaf, Root & Fruit Post author

      Hi Serge,

      We haven’t had that experience at all, even on new growth on young plants. Had the sprayer previously been used for any other products (eg weed killer, copper sulphate?). Perhaps some residues were left which have harmed the leaves?

      Can you please email some photos through to us as info@leafrootfruit.com.au so that we can see the extent of the damage?

      Thanks for the update

      Duncan

      • Serge

        Hi Duncan,
        I did use the spraying tank for feed & weed product on my lawn just before but I thoroughly washed it afterwards.
        I will make some photos and post it to you.
        Regards,
        Serge

  • Harry

    Great citizen scientist analysis, I live in northcote Melbourne. Over the last 20 years galls are now growing on orange trees and not just lemon trees.

    My observation over many years is that galls don’t grow on citrus trees at seaside areas of Victoria. Could salt air be a deterrent to galls?

    Harry

    • Leaf, Root & Fruit Post author

      Hi Harry,

      Thanks for the feedback. I’ve seen many galls on trees in seaside areas and hadn’t noticed the same correlation that you have. I’ll now pay more attention though and see if I can spot a similar trend. Perhaps the milder climate impacts their life cycle?

      Good Luck & Happy Gardening!

      Duncan
